Quick Overview:

This cylinder series is normally equipped with adjustable end-stroke cushioning. Moreover these cylinders are equipped with bumpers in order to reduce noise and the impact of the piston as it reaches the end of the stroke.

* AVAILABLE WITH EXTERNAL MOUNTING ONLY

Features:

COVER: - Bore size 40 - 63 - Cover Bore 80 - 250 - Cast Iron Cover

TUBE: - Bore 40 - 63 Aluminium Bore 80 to 250 - M.S. duly honed & Hard Chrome Plated

SEALS: - Nitrile Suitable for 80°C Max.

COMPARISON TO STANDARD SERIES 50 LUTHRA CYLINDERS

a) More Heavy Duty

b) Mounting Dimensions are totally different

c) Shaft diameter and threads are different compared to series 50 cylinders
